High Precision Moderate 2K Mold Medical&Health Care And Catheter Mold with ISO Standard

Our High Precision Moderate 2K Mold represents the pinnacle of medical device manufacturing technology, specifically engineered for producing sophisticated catheter components and healthcare devices. This advanced mold system integrates dual-material injection capabilities with exceptional precision, meeting the rigorous demands of the medical industry where accuracy, reliability, and patient safety are paramount.

Certified under ISO 13485 for medical devices and ISO 9001 for quality management systems, our molds ensure compliance with international standards for medical manufacturing.

Technical Specifications

Mold Base Configuration

• Mold Type: Two-shot (2K) injection mold with rotary or shuttle table system

• Materials Compatibility: Medical-grade thermoplastics (PP, PE, PVC, TPU, Silicone), bio-compatible resins

• Cavities: 4-32 cavities (configurable based on component size and production requirements)

• Mold Base: Premium hardened steel (1.2344/ H13, Stainless 420)

• Surface Finish: Optical-grade polishing, EDM/texturing as required (Ra ≤ 0.025μm for critical surfaces)

• Cooling System: Conformal cooling channels for optimal thermal management

• Lifespan: 1,000,000+ cycles with proper maintenance

Precision Engineering

• Parallelism/Flatness: ≤ 0.01mm across mold surfaces

• Ejection System: Multi-stage, precision-guided ejection for delicate components

• Venting: Micro-vent systems to eliminate gas traps in thin-walled sections

• Alignment: German-standard precision guide pillars and bushings

2K Injection Capabilities

• Injection Units: Independently controlled dual injection systems

• Overmolding Precision: Layer thickness control down to 0.05mm

• Bonding Technology: Optimized for medical-grade material adhesion

• Process Control: Real-time monitoring of both injection cycles

Medical-Grade Features

Hygiene & Safety Design

• Cleanroom Compatibility: Designed for Class 7/8 (ISO 14644-1) cleanroom installation

• Surface Integrity: Non-porous, corrosion-resistant surfaces preventing bacterial colonization

• Lubrication: Medical-grade, biocompatible lubrication systems

Catheter-Specific Optimizations

• Micro-feature Molding: Capable of producing lumen diameters from 0.3mm to 10mm

• Tip Forming: Precision radius control for atraumatic catheter tips

• Marker Band Integration: Precision placement of radiopaque marker bands

• Surface Texturing: Controlled surface patterning for specific flow characteristics

Quality Assurance & Compliance

Certifications & Standards

• ISO 13485:2016 - Medical Devices Quality Management

• ISO 9001:2015 - Quality Management Systems

• EU Medical Device Regulation (MDR 2017/745) ready

• Material certifications per USP Class VI and ISO 10993 biocompatibility standards

Validation Documentation

• Design Qualification (DQ) package

• Installation Qualification (IQ) protocols

• Operational Qualification (OQ) documentation

• Performance Qualification (PQ) validation

• Complete mold history file with material certificates

Inspection & Testing

• CMM inspection reports for all critical dimensions (Zeiss/Hexagon)

• Mold flow analysis reports (Autodesk Moldflow)

• First-article inspection reports per AIAG PPAP guidelines

• Sample parts with dimensional reports

• Durability testing certificates

Applications in Medical & Healthcare

Primary Applications

• Vascular Catheters: Angiographic, guiding, balloon dilation catheters

• Urological Catheters: Foley, intermittent, ureteral stents

• Neurovascular Devices: Microcatheters, delivery systems

• IV Access Components: Safety IV catheters, needle-free connectors

• Specialty Catheters: PICC lines, dialysis, suction, and drainage catheters

Component Manufacturing

• Multi-durometer catheter shafts

• Tip configurations with varying flexibility

• Connectors and hubs with overmolded seals

• Safety mechanisms with moving parts

• Assembled devices with hard/soft combinations

Technical Support & Services

Design Phase Support

• Design for Manufacturability (DFM) analysis

• Material selection consultation

• Mold flow simulation and optimization

• Prototyping services with quick-turn molds

Manufacturing & Installation

• Complete mold fabrication in controlled environment

• Factory acceptance testing at our facility

• Installation supervision by certified engineers

• Process parameter development and optimization

Maintenance & Lifecycle Support

• Preventive maintenance programs

• Technical documentation including 3D models and drawings

• Spare parts inventory management

• Refurbishment and upgrading services

• 24/7 technical support hotline

Why Choose Our Medical 2K Molds?

Precision Advantage

Our proprietary mold-making technology achieves tolerances 30% tighter than industry standards for medical molds, ensuring consistency across millions of cycles.

Regulatory Expertise

With over 15 years specializing in medical molds, we navigate complex regulatory requirements so you can focus on device development and patient care.

Integrated Validation

We provide complete validation packages that accelerate your own regulatory submissions and reduce time-to-market.

Lifecycle Partnership

From initial concept through mass production and eventual mold refurbishment, we partner throughout your device's commercial lifecycle.

Contact Our Medical Mold Specialists Today

Discuss your specific catheter or medical device requirements with our engineering team. We provide confidential consultations, feasibility studies, and detailed quotations tailored to your project needs.

All manufacturing occurs in our ISO-certified facilities with strict confidentiality agreements to protect your intellectual property.
