We provide High Precision Custom Injection Mold for ABS+UV White RAL9010 Light Blocking Segment Lid, factory direct OEM tooling service with fast prototype & mold delivery. This 1×2 cavity cold runner mold adopts submarine gate design to minimize gate mark on appearance surface, built with 738H pre-hardened steel for stable medium-volume mass production, specially optimized for high-titanium light-blocking ABS formulation to avoid weld-line light leakage and material burning.
✅ Factory Direct Custom Mold Service, DFM & Mold Flow Analysis Available Before Machining
✅ 1×2 Cavity Design, Submarine Gate (Tunnel Gate) for Auto Degating & Clean A-surface
✅ Core & Cavity: 738H Pre-hardened Steel, HRC35-40, Good Polishing & Texture Performance
✅ Optimized for ABS+UV Stabilized RAL9010 White Light Blocking Compound
✅ Controlled Shrinkage 0.5% (1.005), Strict Dimension Control for Light-tight Requirement
✅ Stable Runner & Venting System, Prevent Burning, Silver Streaks & Light Penetration on Weld Line
✅ Long Mold Lifespan, Standard Mold Base (LKM/HASCO/DME Optional)
✅ In-house CNC, EDM, Wire-cut & Mold Trial Service, Full Mold Report After T1
Item | Specification |
|---|---|
Mold Name | Injection Mold for Light Blocking Segment Lid |
Plastic Material | ABS+UV Stabilized, White RAL9010, Light Blocking Grade |
Cavity | 1×2 Cavity |
Shrinkage Rate | 0.5% (1.005) |
Gating System | Cold Runner, Submarine Gate (Tunnel Gate) |
Core & Cavity Steel | 738H, HRC35-40 Pre-hardened Steel |
Mold Base | Optional: LKM / HASCO / DME |
Mold Life | 300,000 ~ 600,000 Shots |
Tolerance | ±0.02mm (Custom Tolerance Acceptable) |
Service | DFM, Moldflow, CNC Machining, Mold Trial, Sample Supply, After-sales Mold Maintenance |
This segment lid is widely used for LED backlight modules, lighting housings, optical shielding assemblies and other applications requiring strict light blocking & UV weather resistance. We also accept custom mold development for other optical shading plastic covers.
We are a professional injection mold manufacturer located in Dongguan, China, focusing on precision plastic tooling for optical, electronic and consumer industries.
Free DFM review before quotation
Moldflow simulation for filling, warp & light-blocking risk prediction
Clear T1 trial schedule & video report
On-time delivery, technical support for mass production
Accept custom steel, cavity, surface texture & drawing modification
Long-term mold maintenance support
Please send us your 3D/2D drawing, material requirement, target mold life & annual volume, we will provide formal quotation & DFM report within 24 hours.
Q1: Can we adjust cavity number or change gate type?
A: Yes, we support 1+1, 1×4 or hot runner modification; gate type can be changed to side gate / pinpoint gate upon your appearance request.
Q2: Is 738H suitable for high filling light-blocking ABS?
A: Yes, 738H pre-hardened steel balances polishability and stability for medium-run production; for higher volume, we can upgrade to 1.2344 or S136.
Q3: Can you provide molded samples after mold trial?
A: Sure, we supply T1 samples for dimension & light blocking test before mass production.
Q4: What file format do you accept?
A: STEP, IGES, STP, X_T, DWG, PDF are all acceptable.
