Key Materials And Requirements for Medical Products Made by Injection Molding

1. Common Materials for Medical Injection Molding

A. Standard Medical Plastics

• Polypropylene (PP)

• Properties: Chemical resistance, autoclavable (gamma/Eto sterilizable), low cost.

• Applications: Syringes, IV bottles, labware.

• Standards: Must comply with ISO 10993 (biocompatibility) and FDA 21 CFR.

• Polyethylene (PE)

• HDPE (High-Density PE): Rigid, used in medicine bottles and catheters.

• LDPE (Low-Density PE): Flexible, ideal for tubing and packaging films.

• Requirements: USP Class VI or ISO 10993-5 certification for cytotoxicity.

• Polycarbonate (PC)

• Properties: High transparency, impact resistance, and steam sterilizable.

• Applications: Blood filters, surgical instrument housings.

• Note: BPA-free grades are preferred due to regulatory concerns.

• Polystyrene (PS)

• General PS: Used in petri dishes, test tubes.

• HIPS (High-Impact PS): Enhanced durability for medical device casings.

• ABS (Acrylonitrile Butadiene Styrene)

• Properties: Strong, easy to mold, good aesthetics.

• Applications: Medical equipment housings, connectors.

• Limitations: Not suitable for long-term implants.

B. High-Performance Engineering Plastics

• PEEK (Polyether Ether Ketone)

• Properties: Extreme heat resistance (250°C+), high strength, radiolucent.

• Applications: Spinal implants, dental tools.

• Certifications: ISO 13485, ASTM F2026.

• Polysulfone (PSU) & Polyethersulfone (PESU)

• Properties: Hydrolysis-resistant, reusable in autoclaves.

• Applications: Surgical instruments, respiratory masks.

• TPE/TPU (Thermoplastic Elastomers)

• Properties: Soft, flexible, fatigue-resistant.

• Applications: Catheters, gaskets, seals.

C. Specialty Materials

• Liquid Silicone Rubber (LSR)

• Properties: Biocompatible, heat-resistant, flexible.

• Applications: Baby bottle nipples, implantable devices.

• Fluoropolymers (PTFE, FEP)

• Properties: Chemically inert, low friction.

• Applications: Cardiovascular stents, catheters.

2. Critical Requirements for Medical-Grade Plastics

1. Biocompatibility

• Must pass ISO 10993 tests (cytotoxicity, sensitization, hemocompatibility).

• Implantable materials require additional standards (e.g., ISO 5832 for orthopedics).

2. Sterilization Compatibility

• Steam Autoclaving (PEEK, PSU).

• Gamma Radiation (PP, PE).

• Ethylene Oxide (EO) Gas (sensitive materials like some TPEs).

• Must withstand sterilization methods:

3. Chemical Resistance

• Should not degrade when exposed to disinfectants (alcohol, hydrogen peroxide) or bodily fluids.

• Avoid plasticizers (e.g., DEHP-free PVC alternatives).

4. Mechanical Performance

• High wear resistance for implants (e.g., PEEK in joint replacements).

• Transparency retention for devices like IV connectors (no stress cracking).

5. Regulatory Compliance

• FDA 21 CFR (U.S. market).

• EU MDR/IVDR (CE marking).

• China NMPA (GB/T 16886 standards).

3. Emerging Trends

• Biodegradable Polymers: PLA and PCL for absorbable sutures and implants.

• Antistatic Compounds: Used in electronic medical housings to prevent dust buildup.

• Colorants & Additives: Must be non-toxic and meet ISO 10993-10.

4. How to Select the Right Material for mold with Biocompatible ?

1. Determine Risk Class: Class I (low risk) vs. Class III (implantable).

2. Evaluate Contact Duration: Short-term (e.g., syringes) vs. permanent implants.

3. Match Sterilization Method: Avoid material degradation (e.g., PC yellowing under gamma radiation).

4. Balance Cost & Performance: PEEK is expensive but unmatched for implants; PEI may be an alternative.

Conclusion

Choosing the right material for medical injection molding involves a careful balance of biocompatibility, sterilization resistance, mechanical properties, and regulatory compliance. By understanding these factors, manufacturers can produce mold with biocompatible safe, effective, and high-quality medical devices that meet global standards.
