YIXUN mold
8480419090
High Precision Molding: The overarching capability. This means producing parts with extremely tight tolerances (often within ±0.01mm to ±0.05mm), excellent repeatability, and superior surface finish. It requires high-end machinery, precise mold making, and controlled processes.
Materials: ABS & PVC
ABS (Acrylonitrile Butadiene Styrene): A very common, versatile, and strong engineering plastic. Good impact resistance, machinability, and surface finish. Widely used for automotive parts, enclosures, consumer products.
PVC (Polyvinyl Chloride): Can be rigid or flexible. Known for its chemical resistance, durability, and low cost. Used for pipes, fittings, medical tubing, and profiles. Important: PVC processing requires special attention as it releases corrosive hydrochloric acid gas when melted; molds and machines need corrosion-resistant materials (like stainless steel).
Mold Technologies:
Hot Runner System: Keeps the plastic in the runners (the channels) molten. Advantages: No runner waste, faster cycle times, fully automated. Best for: High-volume production. Disadvantage: Higher initial mold cost and complexity.
Cold Runner System: The plastic in the runners cools and solidifies with the parts, creating waste material that must be recycled or reground. Advantages: Lower mold cost, easier color/material changes. Best for: Lower volumes, prototypes, or when material changes are frequent.
Different Cavities: This refers to a multi-cavity mold. A single mold has multiple copies (cavities) of the part, allowing multiple parts to be produced per molding cycle. 2, 4, 8, 16, or even more cavities dramatically increase production rates. Design must ensure perfect balance so all cavities fill identically.
Hot Runner vs. Cold Runner: These are systems for delivering molten plastic into the mold cavities.
A Direct Mold Maker with this expertise is not just a mold shop or just a molding house—they are an integrated manufacturer. They handle the entire process from design to finished parts.
Their Complete Service Flow:
Design for Manufacturability (DFM): They will analyze your part design for both moldability and precision, suggesting optimizations for ABS/PVC.
Precision Mold Manufacturing: They build the high-precision mold in-house. This is their core skill. They will:
Choose the right mold steel (hardened steel for longevity, stainless for PVC).
Use high-precision CNC, EDM, and grinding.
Incorporate the requested hot runner or cold runner system.
Design and build a balanced multi-cavity mold for your required output.
In-House Molding & Process Validation: They run the mold on their own high-precision injection molding machines.
They rigorously set up the process (temperature, pressure, cooling) to achieve the specified tolerances for ABS or PVC.
They conduct First Article Inspection (FAI) and process capability studies (Cp/Cpk).
Production & Delivery: They manufacture your production batches, perform quality checks, and deliver finished parts.
To ensure they truly meet your needs, ask:
"What are your standard tolerance capabilities for high-precision parts?" (Get a specific number).
"Can you provide a DFM report for my part, including runner/gate recommendations (hot vs cold) and cavity recommendations?"
"What is your experience with PVC processing, and how do you protect molds from corrosion?"
"For a multi-cavity hot runner mold, how do you ensure cavity-to-cavity consistency (flow balancing)?"
"What metrology equipment do you use for inspection? (e.g., CMM, optical comparators)"
"Can you show examples of similar multi-cavity, high-precision molds you've built for ABS or PVC?"
Medical Components: Connectors, valve parts (PVC, high precision).
Electronics: Small housings, connectors, bezels (ABS, multi-cavity hot runner for volume).
Automotive: Interior switches, sensor housings, ducting components (ABS).
Consumer Goods: High-quality toy parts, appliance components, fittings.
