ABS+UV 1*1 Cavity Large Runner Submarine Gate 738H HRC35-40 Steel Polished Mold Slide VDI 30 Surface Textured Molding Companies Powder Connector Plastic Injection Molding

ABS+UV 1*1 Cavity Large Runner Submarine Gate 738H HRC35-40 Steel Polished Mold Slide VDI 30 Surface Textured Molding Companies Powder Connector Plastic Injection Molding

Name: ABS+UV 1*1 Cavity Large Runner Submarine Gate 738H HRC35-40 Steel Polished Mold Slide VDI 30 Surface Textured Molding Companies Powder Connector Plastic Injection Molding
Brand: yixunmold
Rating: 5.0 (11 reviews)

This is a precision injection-molded Power Connector Housing, designed for electrical and power distribution applications. Manufactured from FDA-grade UV-stabilized ABS (ABS757F), it combines electrical safety, UV resistance, and compliance with strict hygiene standards for versatile use cases.

Quantity:
Availability:





Inquire Add to Basket 天猫购买

Model:
25051
Brand:
yixunmold

Product Description

1. Product Overview

This is a precision injection-molded Power Connector Housing, designed for electrical and power distribution applications. Manufactured from FDA-grade UV-stabilized ABS (ABS757F), it combines electrical safety, UV resistance, and compliance with strict hygiene standards for versatile use cases.

2. Core Specifications

Parameter	Details
Product Name	Power Connector
Material	ABS+UV White 9010 (ABS757F, FDA Food Grade)
Cavity	1×1
Shrinkage Rate	1.005
Gate System	Large Runner Submarine Gate
Front Mold Steel	738H (HRC 35–40)
Back Mold Steel	P20 (HRC 28–36)
Mold Finish	Polished front/back molds, slider surfaces with EDM texture (VDI 30)

ABS+UV 1*1 Cavity Powder Connector Plastic Injection Molding

3. Key Material & Mold Advantages

✅ FDA-Grade ABS757F: Compliant with food-contact regulations, suitable for appliances, medical devices, and hygiene-sensitive applications.

✅ UV-Stabilized Formula: Resists yellowing and degradation in outdoor/UV-exposed environments, maintaining color stability for long-term use.

✅ Low Shrinkage Precision: 1.005 shrinkage rate ensures tight dimensional control for precise connector fit and alignment.

✅ Dual Mold Steel Design:

738H front mold: High polishability for smooth, defect-free appearance surfaces.
P20 back mold: Balanced hardness and toughness for structural stability in high-volume runs.

✅ Hidden Gate System: Submarine gate eliminates visible marks, preserving the housing’s clean aesthetic and reducing post-processing labor.

4. Applications

Household appliances and kitchen equipment (FDA-compliant)
Outdoor electrical enclosures (UV-resistant)
Medical and food processing machinery
Industrial power distribution systems

5. FAQ

Is the material food-safe?

Yes. ABS757F is FDA food-grade, suitable for direct/indirect food contact applications.
Can the color or texture be modified?

Yes. We offer custom Pantone/RAL colors, plus matte/gloss finishes and custom textures via mold polishing or EDM.
What tolerances are achievable?

Tight ±0.05–0.1mm tolerances, supported by first article inspection (FAI) reports.
What is the production lead time?

Mold fabrication: 3–4 weeks. Mass production: 2–4 weeks, based on order quantity.
Do you provide compliance documentation?

Yes. We offer FDA, RoHS, and REACH certificates to support regulatory requirements.

Powder Connector Plastic Injection Molding Polished Mold Slide VDI 30 Surface Textured Molding ABS+UV 1*1 Cavity Powder Connector Plastic Injection Molding

Yixun is the China first generation mold maker, specialize in mold and moulding, provide one-stop plastic manufacturing service, feature in building medical and healthcare device tooling.
