This high-precision 1×2 cavity injection mold is custom-engineered for manufacturing medical-grade ABS plastic housings for laser therapy/medical devices. Constructed with 738H pre-hardened mold steel (HRC35-40), featuring a large submarine gate system and VDI 24 textured cavity finish, this mold delivers consistent dimensional accuracy, sterile-ready surface quality, and long-term stability for medical-grade components. It is optimized for high-volume production of ergonomic laser device housings, meeting strict hygiene and regulatory requirements.

Core Mold Specifications

Parameter	Specification
Product Name	Medical Grade ABS Laser Housing Injection Mold
Cavity Configuration	1×2 Cavity (2 parts per cycle)
Molding Material	Medical-Grade ABS (Acrylonitrile Butadiene Styrene)
Core & Cavity Steel	738H Pre-Hardened Mold Steel
Steel Hardness	HRC 35-40
Gate System	Large Submarine Gate
Cavity Surface Finish	VDI 24 Standard Texture
Molded Application	Laser therapy device housings / medical instrument shells
Key Features	Ergonomic shape, sterile-ready, consistent texture, low warpage

Key Mold Design & Technical Advantages

1. 1×2 Cavity Balanced Production Structure

The 1×2 cavity design produces two identical laser housings in a single cycle, balancing production efficiency and molding stability. Symmetric runner and cooling layouts ensure uniform melt flow and cooling, eliminating dimensional variation or warpage—critical for the ergonomic shape and internal component fit of medical devices.

2. 738H Steel Construction (HRC35-40)

Balanced Toughness & Wear Resistance: 738H pre-hardened steel offers excellent impact resistance and dimensional stability, ideal for molding complex, curved medical ABS parts.
Consistent Texture Reproduction: The steel’s uniform grain structure supports stable VDI 24 texture transfer across high-volume cycles, avoiding texture degradation that would compromise the housing’s appearance and grip.
Cost-Effective Durability: Pre-hardened to HRC35-40, the mold requires no additional heat treatment, reducing lead times while maintaining long service life for medical-grade production.

3. Large Submarine Gate System

Efficient, Balanced Filling: The large submarine gate ensures fast, uniform melt flow into the mold cavity, preventing short shots, flow marks, or sink marks on the textured VDI 24 surface.
Automatic Gate Break: The hidden gate separates cleanly during ejection, leaving minimal gate residue on the part surface. This eliminates manual trimming, reducing contamination risks in medical-grade components and preserving the housing’s sterile-ready finish.
Low Shear Stress: The gate geometry minimizes shear heat buildup, protecting the medical-grade ABS material from degradation and ensuring consistent part color and biocompatibility.

4. VDI 24 Textured Cavity Finish

The mold cavity is finished to VDI 24 standard, creating a uniform matte, anti-slip texture on the housing’s outer surface. Key benefits include:

Ergonomic Grip: The texture enhances user comfort and control during medical device operation, reducing the risk of slippage.
Defect Hiding: The matte finish hides minor molding imperfections and fingerprints, maintaining a professional, clean appearance suitable for clinical environments.
Consistent Quality: The standardized texture ensures uniform surface quality across all molded parts, supporting brand and regulatory compliance.

Mold Performance Comparison

Feature	Our 738H 1×2 Medical Housing Mold	Standard Industrial Housing Mold
Cavity Configuration	1×2 balanced, medical-grade production	Low-cavity or unbalanced multi-cavity
Steel Grade	738H HRC35-40, medical-grade durability	Generic P20/45# steel, prone to wear
Gate System	Large submarine gate, no trimming, low contamination risk	Cold side gate, requires manual finishing
Surface Finish	VDI 24 textured, ergonomic & clean	Basic polish or inconsistent texture
Medical Compliance	Optimized for medical-grade ABS, low shear degradation	Not tailored for biocompatible materials
Service Life	300,000–500,000 shots with stable quality	Prone to texture and dimensional degradation

Applications & Benefits

This mold is purpose-built for manufacturing ergonomic ABS housings for a wide range of medical laser devices, including:

Skin therapy laser devices
Dental laser treatment tools
Ophthalmic laser equipment
Physiotherapy laser instruments

Key benefits include:

Regulatory Readiness: Molded parts meet medical-grade material and surface quality standards, supporting compliance with ISO 13485 and other global regulations.
Ergonomic Design: The VDI 24 texture and balanced molding ensure comfortable, non-slip use in clinical settings.
Cost-Effective Mass Production: The 1×2 cavity design reduces per-unit costs while maintaining strict quality standards.
Long-Term Reliability: 738H steel construction minimizes mold wear, ensuring consistent performance across years of production.

Quality & Compliance

All molds undergo rigorous CNC machining, EDM texture validation, and mold trials before delivery. We provide complete documentation, including steel material certificates, texture validation reports, and trial sample data, ensuring the mold meets your production and quality requirements for medical-grade laser housings.

FAQ

Q1: Why use 738H steel for medical ABS housing molds?

A1: 738H pre-hardened steel offers excellent toughness, wear resistance, and texture stability, making it ideal for maintaining the VDI 24 finish and dimensional accuracy of complex medical ABS parts over high-volume cycles.

Q2: What are the benefits of the large submarine gate for medical parts?

A2: The submarine gate ensures balanced filling, automatic gate separation, and no visible residue, eliminating manual trimming and reducing contamination risks in sterile medical components.

Q3: Is the VDI 24 texture suitable for medical device use?

A3: Yes, the VDI 24 matte texture provides a non-slip, easy-to-clean surface that hides minor defects, making it ideal for medical device housings used in clinical environments.

Q4: What is the expected service life of this mold?

A4: With proper maintenance, the 738H steel mold supports 300,000–500,000 shots of medical-grade ABS parts, maintaining consistent quality throughout its lifespan.
