This is a high-precision 1×1 cavity injection mold engineered for producing structural plastic panels from PA6 + 30% glass fiber reinforced material. Built with premium 2083H mold steel (hardened to HRC 29-34), this mold features a pin-point sprue gate and VDI 21 EDM texture on the core surface, delivering dimensionally accurate, functional panels with a consistent, fine finish. It is ideal for manufacturing rigid, high-strength plastic panels for automotive, electronics, and industrial equipment applications.

Quantity:
Availability:





Inquire Add to Basket 天猫购买

Model:
23107
Brand:
YIXUN mold
Code:
8480419090

Product Description

Product Overview

This is a high-precision 1×1 cavity injection mold engineered for producing structural plastic panels from PA6 + 30% glass fiber reinforced material. Built with premium 2083H mold steel (hardened to HRC 29-34), this mold features a pin-point sprue gate and VDI 21 EDM texture on the core surface, delivering dimensionally accurate, functional panels with a consistent, fine finish. It is ideal for manufacturing rigid, high-strength plastic panels for automotive, electronics, and industrial equipment applications.

Mold Specifications

Parameter	Details
Mold Type	1×1 Cavity High Precision Plastic Panel Injection Mold
Compatible Material	PA6 + 30% Glass Fiber Reinforced Nylon
Runner & Gate System	Pin-point Sprue (Pin Gate)
Mold Steel	2083H Stainless Mold Steel, HRC 29-34 Hardness
Core Surface Treatment	EDM Texture VDI 21 Standard
Key Capabilities	High dimensional accuracy, consistent texture, low warpage, stable molding
Application	Automotive interior panels, electronic equipment housings, industrial structural panels

Core Features & Advantages

✅ Optimized for PA6 + 30% Glass Fiber Reinforced Material

This mold is specifically designed to handle PA6 with 30% glass fiber, a material known for its high strength, rigidity, and dimensional stability. The mold’s robust design and runner system are optimized to manage the material’s high melt viscosity and abrasive nature, preventing common issues like uneven filling, excessive wear, and part warpage. It ensures the final panels retain their structural integrity and mechanical properties.

✅ Pin-point Sprue (Pin Gate) System for Clean Parts

The mold uses a pin-point sprue gate design, which leaves a minimal, almost invisible gate mark on the finished panel. The gate automatically breaks during ejection, eliminating the need for manual trimming and secondary operations. This is ideal for panels where surface aesthetics and assembly precision are critical, ensuring a clean, burr-free appearance.

✅ Premium 2083H Mold Steel (HRC 29-34)

Constructed from high-quality 2083H stainless mold steel, this mold offers excellent corrosion resistance, polishability, and dimensional stability. The steel’s HRC 29-34 hardness provides sufficient wear resistance for molding glass-filled PA6, while maintaining excellent surface finish capabilities for EDM texturing. This ensures a long mold life with consistent part quality, even with continuous production.

✅ Core with VDI 21 EDM Texture

The core surface is finished with a standard VDI 21 EDM texture, a fine, uniform grain pattern that provides a subtle matte appearance and excellent anti-slip properties. This texture is precisely transferred to the plastic panel, ensuring consistent finish across all production runs. It also helps hide minor surface imperfections and improves grip, making it ideal for functional and semi-aesthetic panels.

✅ High Precision & Dimensional Stability

Engineered for high-precision panel molding, the mold features tight tolerances on critical dimensions and a balanced cooling system. This minimizes warpage, shrinkage, and distortion in the glass-filled PA6 parts, ensuring the panels meet strict assembly and fit requirements for automotive and industrial applications. The 1×1 cavity design allows for focused process control, further enhancing precision.

✅ Durable & Low Maintenance Design

The 2083H steel’s corrosion resistance and the VDI 21 texture’s low-maintenance finish reduce the need for frequent cleaning and polishing. The pin-point gate system also minimizes runner waste and cleanup. This results in a robust, low-maintenance mold that delivers consistent performance over thousands of cycles.

Application Scope

This mold is ideal for manufacturing high-strength plastic panels for:

Automotive interior components (e.g., door panels, console parts)
Electronic equipment housings and structural frames
Industrial machinery covers and support panels
Consumer appliances requiring rigid, impact-resistant plastic parts

Why Choose This Mold?

✅ 1×1 cavity design for focused precision and process control
✅ Optimized for PA6 + 30% glass fiber reinforced materials
✅ Pin-point sprue gate for clean, burr-free panel surfaces
✅ 2083H stainless steel with VDI 21 EDM texture for consistent finish
✅ High dimensional accuracy and low warpage in glass-filled parts
✅ Durable, corrosion-resistant construction for long mold life

FAQ

Q: What is the benefit of VDI 21 texture on the core?

A: VDI 21 is a standard EDM texture that provides a fine, uniform matte finish. It improves the panel’s grip, hides minor surface defects, and ensures a consistent appearance, all while being easy to maintain.

Q: Can this mold handle other glass-filled PA grades?

A: Yes, the mold is compatible with similar glass-filled PA6 grades (e.g., 15-30% GF). The robust runner and steel design can accommodate variations in material flow and abrasiveness.

Q: Does the pin-point gate affect the part’s structural integrity?

A: No. The pin-point gate is strategically placed to minimize impact on the panel’s critical areas. The gate breaks cleanly during ejection, leaving a tiny mark that does not compromise the part’s strength or fit.
