Product Overview
This is a high-precision 1×1 single-cavity injection mold custom-engineered for manufacturing the main body of ABS plastic king weight scales. Constructed with premium LKM738H (core/cavity) and P20 (mold base) steel, the mold features both polished and etched surface treatments, perfectly balancing functional durability and consumer-grade appearance. Optimized for ABS material molding, it delivers consistent dimensional accuracy, stable texture reproduction, and long service life for mass production of household weighing scale housings.
Core Mold Specifications
| Item | Specification |
| Product Name | ABS King Weight Scale Body Injection Mold |
| Cavity Configuration | 1×1 Single Cavity |
| Molded Material | ABS (Acrylonitrile Butadiene Styrene) Plastic |
| Core & Cavity Steel | LKM738H High-Grade Mold Steel |
| Mold Base Steel | P20 Mold Steel |
| Surface Treatment | Polished + Etched Mold Texture |
| Molded Product | King weight scale main body/housing |
| Key Features | High dimensional stability, precise texture reproduction, low warpage |
| Application | Household digital weighing scale structural housings |
![King Weight Scale Body Injection Mold]( "King Weight Scale Body Injection Mold")
Key Mold Design & Technical Advantages
1. 1×1 Single Cavity Structure for Precision Control
The single-cavity design eliminates cavity-to-cavity variation, ensuring every scale body maintains identical dimensions, wall thickness, and surface quality. This is critical for the structural integrity and aesthetic consistency of weighing scale housings, where fit and finish directly impact product quality.
2. Dual Steel Combination: LKM738H Core/Cavity + P20 Mold Base
LKM738H Core & Cavity: This pre-hardened steel offers excellent toughness, wear resistance, and polishability. It is ideal for ABS molding, resisting cavity wear and deformation even in long production runs.
P20 Mold Base: Provides a stable, cost-effective foundation with good machinability and strength, supporting the core/cavity while reducing overall mold cost.
This combination balances performance and cost, delivering long mold life without unnecessary over-investment.
3. Dual Surface Treatment: Polished + Etched Texture
The mold features a combination of polished and etched surfaces to meet the scale body’s functional and aesthetic needs:
Polished Areas: Produce smooth, glossy sections (e.g., display window frames, top surfaces) for a clean, premium appearance.
Etched Texture Areas: Create non-slip, matte or patterned surfaces (e.g., side panels, bottom sections) that hide fingerprints and minor scratches, improving user experience.
The mold is engineered to reproduce these textures consistently across every shot.
4. ABS-Optimized Molding Performance
The mold’s design is tailored for ABS material, which offers good impact resistance and dimensional stability for scale housings:
Optimized cooling channels to minimize warpage, a common issue with large ABS parts.
Balanced gate placement to ensure uniform melt flow, preventing sink marks or flow lines on visible surfaces.
Robust ejection system to handle the rigid scale body without deformation during demolding.
Mold Performance Comparison
| Feature | Our LKM738H + P20 Scale Mold | Ordinary Generic Mold |
| Steel Grade | LKM738H core + P20 base | Generic P20 only or low-grade steel |
| Surface Treatment | Polished + etched texture, precise reproduction | Basic finish or inconsistent texture |
| ABS Molding | Optimized cooling/gating, low warpage | Prone to sink marks, warpage, and flow lines |
| Dimensional Stability | High consistency for scale fit and assembly | Frequent dimensional variation |
| Service Life | Long wear resistance for high-volume runs | Prone to cavity wear and texture degradation |
Application & Benefits
This mold is purpose-built for producing the main body of king weight scales, offering key benefits:
Structural Durability: The rigid ABS housing provides a stable base for internal weighing components.
Consumer Appeal: The combination of polished and etched surfaces creates a high-quality, user-friendly appearance.
Cost-Effective Production: The balanced steel combination and single-cavity design reduce per-part costs while maintaining quality.
Reliable Assembly: Consistent dimensions ensure a perfect fit for buttons, displays, and internal mechanisms.
Quality Assurance
All molds undergo rigorous CNC machining, surface treatment, and mold trials before delivery. We provide complete documentation, including steel material reports, texture validation records, and trial sample data, ensuring the mold meets your production and quality requirements.
