YIXUN mold
8480419090
This precision single-cavity injection mold adopts standard LKM808E mold base, equipped with reliable submarine gate feeding structure, specially customized for mass production of ABS industrial cloth weaving tool plastic components. Manufactured under ISO 9001 standardized quality management system, the mold features high-precision cavity machining, excellent surface replication capability and stable long-running performance, which effectively guarantees high dimensional consistency and smooth appearance of textile machinery spare parts, perfectly meeting continuous batch production demands of textile equipment manufacturers.
Adopts original LKM808E standardized mold base with high structural rigidity, excellent compression and deformation resistance, which can withstand high injection pressure during ABS material molding and avoid mold expansion or displacement after long-term repeated opening and closing.
Standardized hole position, guide pin and positioning structure design realizes quick installation on various mainstream injection molding machines, greatly shortening mold commissioning time and improving production line switching efficiency.
Precise fit tolerance between guide pins and guide sleeves ensures stable mold alignment, effectively preventing flash, burr and dimensional deviation of thin-wall textile tool plastic parts.
Equipped with hidden submarine gate design, the gate mark is concealed on the inner surface of cloth weaving tool, no obvious injection trace on the outer appearance, eliminating secondary gate trimming process and greatly saving post-processing labor cost.
The submarine gate achieves automatic shear during mold ejection, realizing fully automatic unmanned continuous production, which is highly suitable for high-volume mass production of textile machinery spare parts.
Optimized runner and gate size layout ensures smooth melt flow of ABS material, effectively avoiding short shot, weld line, air trap and material burning defects for long narrow weaving tool structural parts.
Mold cavity is processed by high-precision CNC + wire EDM technology, strictly controlled within ±0.015mm dimensional tolerance, accurately reproducing the slotted, porous and ribbed structural features of cloth weaving tools to guarantee interchangeability of textile equipment spare parts.
Optional pre-hardened mold steel like 718H / NAK80, with good polishing performance, can realize high-gloss or VDI textured surface, perfectly adapting to ABS raw material molding, resisting wear and corrosion from long-term continuous production, standard service life reaches 500,000–1,000,000 shots.
Balanced circulating cooling channel layout ensures uniform mold temperature distribution, effectively reducing warpage and shrinkage deformation of slender weaving tool parts, stabilizing product dimensional consistency in mass batches.
| Item | Detailed Parameter |
|---|---|
| Mold Cavity | 1+1 Single Cavity Design |
| Standard Mold Base | LKM808E Standard Mold Base |
| Gate Type | Submarine Hidden Gate |
| Applicable Raw Material | ABS Engineering Plastic |
| Quality Certification | ISO 9001 Quality Management System Certified |
| Optional Mold Steel | 718H / NAK80 Pre-hardened Mold Steel |
| Dimensional Tolerance | ±0.015mm High Precision Control |
| Standard Mold Lifespan | 500,000 ~ 1,000,000 Shots |
| Cavity Surface Treatment | High Gloss Mirror Polishing / VDI Etching Texture |
| Cooling System | Balanced Circulating Water Cooling Channel |
Textile machinery cloth weaving equipment plastic threading tools, loom auxiliary spare parts
Industrial textile machine positioning fixtures, yarn guiding and tension adjustment plastic components
Garment factory automatic weaving, sewing equipment plastic functional tool housings
Non-woven fabric production equipment slender structural plastic accessories
Textile automation equipment maintenance replacement spare plastic parts
Rich experience in textile machinery spare part mold development, proficient in slender thin-wall ABS part molding technology, able to effectively solve warpage, air trap and weld line common defects of long strip industrial plastic tools.
Adopts authentic LKM standard mold base with complete original certification, stable mold performance, convenient after-sales maintenance and universal compatibility with global mainstream injection molding equipment.
One-stop customized service: DFM structural optimization, mold flow analysis, precision mold manufacturing, multi-round sample trial, dimensional calibration and technical after-sales support.
Strict IP confidentiality protection, sign exclusive NDA agreements for all customer textile equipment drawings and technical solutions to prevent design leakage.
